    Ym320 Automatic Carton Box Two Sides Sticker Corner Sealing Machine Plastic Paper Big Box Labeling Machine

    Ask Lasest Price
    Brand Name : YIMU
    Model Number : YM215
    Certification : CE SGS
    Price : $3,100.00/sets 1-2 sets
    Payment Terms : D/P, T/T, MoneyGram
    Supply Ability : 20 Set/Sets per Month
    Delivery Time : 7-20days
    • Product Details
    • Company Profile

    Ym320 Automatic Carton Box Two Sides Sticker Corner Sealing Machine Plastic Paper Big Box Labeling Machine

    APPLICATION
    Ym320 Automatic Carton Box Two Sides Sticker Corner Sealing Machine Plastic Paper Big Box Labeling Machine
    PRODUCTS DESCRIPTION
    1. For automatic labeling on side flat drum, carton, box, pallet and any big heavy product for the pharmaceuticals, daily chemicals, food& beverages industries. 2. The labeller will automatically detects label size and set the appropriate labeling parameters, a very useful feature for users with multiple products to label. 3. It is an optimal combination of speed,accuracy,stability,GMP standards, easy use, and flexibility. 4. Machine strong labeling for corner of two sides, any different size carton and labels are no problem on this machine. 5. PLC combined with human/machine interface digital LCD touch screen controller. 6. Labeling speed is automatically synchronized with conveyor speed to ensure quality labeling. 7. The kind machine can working without conveyor, it only put along of existing conveyor, it's very convenient and smart.
    PRODUCT PARAMENTERS
    1
    Label width(height)
    5-180mm
    2
    Label length
    5-200mm
    3
    Capacity
    20-200pcs/min(can be customized)
    4
    Conveyor speed
    0-30m/min
    5
    Labeling accuracy
    ±1mm
    6
    Power supply
    400W , 220V,50Hz/60Hz (customized)
    7
    Label reel Inner diameter
    76mm or 40mm
    8
    Label reel outer diameter
    Max 380mm
    9
    Machine size
    L1000 * W600 * H1700 mm
    10
    Machine net weight
    150KG
    11
    Online printer
    Optional
    12
    Control system
    Japanese Mitsubishi PLC
    MAIN CONFIGURATION LIST
    PLC
    SIEMENS / MITSUBISHI
    HMI
    SIEMENS / WEINVIEW
    Motor
    RAYNEN servo motor / KINCO stepper motor
    Sensor
    SICK / KEYENCE / PANASONIC
    Touches screen
    WEINVIEW (Taiwan)
    Frequency changer
    Schneider(Germany)
    Stainless steel material
    304SS
    Ym320 Automatic Carton Box Two Sides Sticker Corner Sealing Machine Plastic Paper Big Box Labeling Machine
    DETAILS IMAGES
